9039250035050| Thread Size (Inch) | #6-32 |
| Thread Standard | UNC |
| Chamfer | Plug |
| Material | HSS-E Cobalt |
| Coating/Finish | Bright/Uncoated |
| Thread Direction | Right Hand |
| Coolant Through | No |
| Class Of Fit | 2B |
| Thread Limit | H3/H4 |
| Number Of Flutes | 3 |
| Oversize | No |
| Interrupted Thread | No |
| Threads per Inch | 32 |
| Overall Length (Inch) | 2 |
| Thread Pitch (Decimal Inch) | 0.0313 |
| Thread Length (Decimal Inch) | 0.7480 |
| Overall Length (Decimal Inch) | 2 |
| Cnc Shank | Yes |
| Shank Diameter (Decimal Inch) | 0.1410 |
| Application | Through-Hole Threading |
| Neck Length (Decimal Inch) | 0.7480 |
| Tapping Depth (Decimal Inch) | 0.7480 |
| Square Length (Inch) | 7/64 |
| Square Length (Decimal Inch) | 0.1100 |
| Square Size (Decimal Inch) | 0.11 |
| Material Application | Non-Ferrous Metal |
| Series | 3925 |
| Style | Spiral Point |
| UNSPSC Code | 23241600 |
