02464702| Informacion Tecnica del Manufacturador (Se abre en otra ventana) | Seco |
| Insert Style | CCGW |
| Insert Size Code | 32.51 |
| Insert Shape | Diamond |
| Included Angle | 80 |
| Inscribed Circle (Decimal Inch) | 0.375 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Insert Material | Polycrystalline Cubic Boron Nitride (PCBN) |
| Manufacturer Grade | CBN200 |
| Coating/Finish | Bright/Uncoated |
| Relief Angle | 7 |
| Wiper Edge | No |
| Insert Thickness (Decimal Inch) | 0.1563 |
| Insert Hand | Neutral |
| Number Of Cutting Edges | 2 |
| Insert Shape Code | C |
| Corner Radius (Inch) | ene-64 |
| Hole Diameter (Decimal Inch) | 0.1772 |
| Maximum Depth of Cut (Decimal Inch) | 0.1146 |
| Inscribed Circle (Inch) | 03-ago |
| Insert Holding Method | Screw |
| Width (Inch) | 03-ago |
| Insert Thickness (Inch) | may-32 |
| Clearance Code | C |
| Tolerance Code | G |
| Series | CCGW-Flat Top |
| Coating Process | PCBN |
| Length Range (Decimal Inch) | 0.3000 – 0.4000 |
| Rake | Positive |
| Insert Length (Decimal Inch) | 0.3819 |
| Primary Workpiece Material | Cast Iron |
| Primary Workpiece Material Code | K |
| Secondary Workpiece Material | Hard Material; Super-alloys & Titanium |
| Secondary Workpiece Material Code | S; H |
| Iso Code | CCGW09T304S-01020-LF |
| Standards | ISO; ANSI |
| Manufacturers Catalog Number | 2464702 |
| Material Grade | K20; K10 |
| Single or Multi Tipped | Multi Tipped |
| Proprietary Coating Designation | Uncoated |
| UNSPSC Code | 23242105 |
| Lead Angle | 80 |
| Coating Classification | Uncoated |
| Chip Breaker | Flat Top |
| Rake Angle | 0 |
| Cutting Edge Style | Chamfered & Honed |
| Industry Standard Number | CCGW32.51S-00420-LF |
| Width (Decimal Inch – 4 Decimals) | 0.375 |
| Multi-Use Tool | Yes |
| Full Radius | No |
| Multi-Use Application | Facing; Turning; Boring |
