38067| Web Site del Mfg | OSG |
| Web Comparativa | MSC |
| Series Description | General Application End Mill |
| High Performance | No |
| End Configuration | Corner Radius |
| Unit (inch/mm) | inch |
| Number of Flutes | 4 |
| Primary Workpiece Material | (P) Steel|(M) Stainless Steel|(K) Cast Iron|(N) Non-Ferrous Materials|(S) High Temp Alloy |
| Secondary Workpiece Material | (H) Hardened Materials |
| Cutting Diameter (DC) (Decimal Inch) | 0.5 |
| Cutting Diameter (DC) (Fractional Inch) | 1/2 |
| Cutting Diameter (DC) (mm) | 12.7 |
| Shank Diameter (DCON) (Decimal Inch) | 0.5 |
| Shank Diameter (DCON) (mm) | 12.7 |
| Length of Cut (APMX) (Decimal Inch) | 1 |
| Length of Cut (APMX) (Fractional Inch) | 1 |
| Length of Cut (APMX) (mm) | 25.4 |
| Overall Length (LF) (Decimal Inch) | 3 |
| Overall Length (LF) (Fractional Inch) | 3 |
| Overall Length (LF) (mm) | 76.2 |
| Corner Radius (RE) (Decimal Inch) | 0.06 |
| Corner Radius (RE) (mm) | 1.52 |
| Shank Length (LS) (Decimal Inch) | 2 |
| Shank Length (LS) (Fractional Inch) | 2 |
| Cutting Diameter (DC) Tolerance (Decimal Inch) | 0/-0.002 |
| Cutting Diameter (DC) Tolerance (mm) | 0/-0.05 |
| Shank Diameter (DCON) Tolerance (ISO) | h6 |
| Corner Radius (RE) Tolerance (Decimal Inch) | 0/-0.002 |
| Corner Radius (RE) Tolerance (mm) | 0/-0.05 |
| Shank Type | Weldon (Drive Flat) |
| Coolant Option | External Coolant |
| Coating Description | Bright/Uncoated |
| Additional Geometry | Right Hand Cut Direction (RHC) |
| Rake Angle | Positive |
| Helix Angle | Right Spiral |
| Helix Angle (Degree) | 30 |
| Variable Helix | No |
| Center Cutting | Yes |
| Chip Breaker | No |
| Shipping Weight | 0.276 |
| Series | 01C |
| Weldon Flat | Yes |
| US Stock | 59 |
| Shank Length (LS) (mm) | 50.8 |
| Shank Diameter (DCON) (Fractional Inch) | ´1/2 |
| Tool Length | Stub |
01843341 38067 86800166 12182593 79123097 496-5006 65039620 C61899 91264457 74560 33734 86625993 88246566 SCM15610J 62779889 6503745 F2014NNH1/2ZR.060DA 13643721 65114316 C60045 00427898 11150005 13636139 F2014NNL1/2ZR.060DA
