32169| Item MFG | Fullerton |
| Cutting Diameter (Decimal Inch) | 0.6250″ |
| Cutting Diameter (mm) | 15.88mm |
| Cutting Diameter (Inch) | 5/8″ |
| Cutting Flute Length (Decimal Inch) | 1″ |
| Cutting Flute Length (mm) | 25.40mm |
| Cutting Flute Length (Inch) | 1″ |
| Shank Diameter (Decimal Inch) | 0.6250″ |
| Shank Diameter (mm) | 15.88mm |
| Shank Diameter (Inch) | 5/8″ |
| Overall Length (Decimal Inch) | 3.5000″ |
| Overall Length (mm) | 88.90mm |
| Overall Length (Inch) | 3-1/2″ |
| Coating/Finish | Uncoated |
| Metric/Inch | Inch |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 30 |
| Flute Spiral Direction | Right Hand |
| Direction of Cut | Right Hand |
| Point End Type | Ball |
| End Type Character Designation | B |
| End Type | Single End |
| Coolant Through | Non Coolant Through |
| Weldon Flat | No |
| Length | Stub |
| Length Designator | STB |
