5-134-0069| Drill Bit Size (mm) | 1.75 |
| Drill Bit Size (Decimal Inch) | 0.0689 |
| Drill Bit Material | High Speed Steel |
| Drill Point Angle (Degrees) | 118 |
| Coating/Finish | TiN |
| Spiral Type | Regular |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Point Type | Standard |
| Primary Workpiece Material | Cast Iron; Steel |
| Specification Number | DIN 338 |
| Coolant Through | No |
| Primary Workpiece Material Code | P; K |
| Shank Diameter (Decimal Inch) | 0.0689 |
| Overall Length (mm) | 46.00 |
| Overall Length (Decimal Inch) | 1.8110 |
| Flute Length (mm) | 22.00 |
| Flute Length (Decimal Inch) | 0.8661 |
| Series | 651 |
| Flute By Diameter Ratio | 5xD |
| Shank Diameter (mm) | 1.75 |
| Maximum Drilling Depth (Decimal Inch) | 0.8661 |
| Maximum Drilling Depth (mm) | 22.00 |
| Shank Length (mm) | 24.00 |
| Shank Length (Decimal Inch) | 0.9449 |
| Drill Bit Diameter Tolerance | +0.000 to -0.014 mm |
| Web Thinning | Web-Thinned |
| Web Configuration | Tapered |
| Tool Performance | General Purpose |
| Shank Type | Straight-Cylindrical |
| Standards | DIN 338 |
| Number of Flutes | 2 |
| Drill Bit Grade | General Purpose |
| Drill Bit Size Range (Decimal Inch) | 0.0500 – 0.1000 |
| Drill Bit Size Range (mm) | 0.00 – 2.00 |
| Material Grade | M2 |
| Specification Designation | DIN |
| UNSPSC Code | 23241634 |
5-134-0069, 57593626, 70364, 00992941, 9006510017500
