5-174-0043| Item Comparativo | MSC |
| Drill Bit Size (mm) | 1.01 |
| Drill Bit Size (Decimal Inch) | 0.0398 |
| Drill Bit Material | Cobalt |
| Drill Point Angle (Degrees) | 118 |
| Coating/Finish | Straw |
| Flute Type | Regular Spiral |
| Cutting Direction | Right Hand |
| Point Type | Cone Relief |
| Primary Workpiece Material | Cast Iron; Steel |
| Coolant Through | No |
| Number of Flutes | 2 |
| Shank Diameter (Decimal Inch) | 0.4375 |
| Overall Length (mm) | 34.00 |
| Overall Length (Decimal Inch) | 1.3386 |
| Spiral Type | Regular |
| Flute Length (mm) | 12.00 |
| Flute Length (Decimal Inch) | 0.4724 |
| Proprietary Coating/Finish | Steam Oxide |
| Flute By Diameter Ratio | 5xD |
| Shank Diameter (mm) | 1.01 |
| Maximum Drilling Depth (Decimal Inch) | 1.3750 |
| Web Thinning | Web-Thinned |
| Drill Bit Grade | General Purpose |
| Drill Bit Size Range (Decimal Inch) | 0.0000 – 0.0500 |
| Drill Bit Size Range (mm) | 0.00 – 2.00 |
| Specification Designation | DIN |
| UNSPSC Code | 23241634 |
